简介： P4.81 indoor/outdoor led display is one of the widely used led display in the market now, usually applied in commercial ads, stadium, stage rental...... Features: 1. High definition 2. only5kglightweight 3. IP30 protection 4. frontmaintenancedesign 5. high cost performance, 30% cheaper. Indoor/OutdoorP4.81ledscreen Physic...
P4.81 indoor/outdoor led display is one of the widely used led display in the
market now, usually applied in commercial ads, stadium, stage rental......
Features:
1. High definition
| Indoor/Outdoor P4.81 led screen | |
| Physical parameters: | |
| Pixel pitch | P4.81 |
| Physical density | 43222 dots/m2 |
| Led packing | SMD2121 |
| LED composition | 1R1G1B |
| Cabinet size | 500x500mm/500x1000mm |
| Caninet weight | 6 kg/12kg |
| Cabinet material | Die-casting aluminum/Iron |
| Optoelectronic parameters | |
| AC operation voltage | 100~120V/220~240V |
| Scan | 1/13S |
| Brightness | indoor 900cd/m2 ;outdoor 3800cd/m2 |
| Gray level | 14 bit |
| View distance | 4~50m |
| View angle | 140 degree horizon/vertical |
| Refresh rate | ≥1920 |
| Life span | 100,000h |
| Frame frequency | ≥60Hz |
| IP rate | indoor IP30/outdoor IP65 |
