类别：固装系列
简介： Lifetime free maintenance Waterproof outdoor p8 full color hd fixed led display is one of the widely used led display in the market now, usually applied in commercial ads, stadium, stage rental...... Features: 1. High definition 2. IP65 protection 3. frontmaintenancedesign 4. high cost performance, 30% cheaper. OutdoorP8ledscreen ...
Lifetime free maintenance Waterproof outdoor p8 full color hd fixed led display is one of the widely used led display in the
market now, usually applied in commercial ads, stadium, stage rental......
Features:
1. High definition
| Outdoor P8 led screen | |
| Physical parameters | |
| Pixel pitch | P8 |
| Physical density | 15625 dots/m2 |
| Led packing | SMD3535 |
| LED composition | 1R1G1B |
| Cabinet size | 640x640mm/1024x1024mm |
| Caninet weight | 12kg/30kg |
| Cabinet material | Die-casting aluminum/Iron |
| Optoelectronic parameters | |
| AC operation voltage | 100~120V/220~240V |
| Scan | 1/4 S |
| Brightness | 7500cd/m2 |
| Gray level | 14 bit |
| View distance | 6~50m |
| View angle | 140 degree horizon/vertical |
| Refresh rate | ≥1920 |
| Life span | 100,000h |
| Frame frequency | ≥60Hz |
| IP rate | indoor IP30/outdoor IP65 |
